ANSI B16.5 Wafer Flanged Ball Valve Stainless Steel Soft Seated For Gas

Large Image : ANSI B16.5 Wafer Flanged Ball Valve Stainless Steel Soft Seated For Gas

Product Details:

Place of Origin:	Made in China
Brand Name:	TEKO
Certification:	CE/PED, API
Model Number:	Q71F

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	By negotiation
Packaging Details:	By export wooden cases
Delivery Time:	15 working days after deposit
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per year

Contact Now

Detailed Product Description

Driven By:	Lever Or Pneumatic	Body Material:	WCB, CF8M, CF8, CF3, CF3M
Top Flange:	ISO 5211	Seat Material:	RPTFE, PTFE
Working Temperature:	-25~-425℃	End Connection:	Wafer
High Light:	ANSI B16.5 Flanged Ball Valve , Stainless Steel Flanged Ball Valve , CF3M Flanged Ball Valve

Stainless Steel Soft Seated ANSI B16.5 Wafer Flanged Ball Valve For Gas

Key Features:

Available in sizes 1/2" to 6"
Stainless steel body and ball
PTFE filled with 15% glass fiber seat
PN16 flanged ends
Blowout proof stem
Working temperature: -20°C to +180°C
Maximum working pressure: 16 bar

Design Standards

DIN 2501 / DIN 2526 –
PN10/16, ANSI B16.5, EN 1092-1
Top flange ISO 5211

Material List

No.	PART NAME	MATERIAL
1	BODY	AISI 316 - CF8M
2	END CONNECTION	AISI 316
3	BALL	AISI 316
4	BALL SEATS	P.T.F.E + 15% GLASS
5	RING	FKM (Viton)
6	THRUST WASHER	P.T.F.E
7	RING	FKM (Viton)
8	STEM SEAL	P.T.F.E
9	PACKING GLAND	STEEL
10	END STOP	AISI 430 (DN 10 - DN 50) STEEL (DN 65 - DN 200)
11	SPRING WASHER	STEEL
12	NUT	STEEL
13	STEM	AISI 316
14	HANDLE	STEEL
15	HANDLE DN 150-200	STEEL
16	SCREW	STEEL
17	SCREW	STEEL
18	BODY HANDLE DN150-200	CAST IRON

Duty

· Water
· Steam
· Gas
· Oil
· Alkalines
· Acids
· Solvents
· Fuel
