Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing

China Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing supplier
Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing supplier Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing supplier

Large Image :  Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing

Product Details:

Place of Origin: Made in China
Brand Name: TEKO
Certification: CE/PED, API
Model Number: GJ641X

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: By negotiation
Packaging Details: By export wooden cases
Delivery Time: 25 working days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000 pcs per month
Contact Now
Detailed Product Description
Operation: Single Acting Pneumatic, Gear Sleeve: Natural Rubber, EPDM, NBR Etc
Standard Or Nonstandard: Nonstandard Opening Tag: Optional
Flange End: DIN 10 /ANSI 150 Body Material: Fabricated Steel Or Cast Iron

Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing



Features

  • Robust and versatile actuators receptive of positioners of leading manufacturers
  • Exterior as well as interior corrosion resistant Fusion Bonded Epoxy Powder coating
  • In-line and quick tube change with tube folds for durability & self-cleaning
  • Sleeve enhanced with fabric cord for high pressure applications



Available Configuration

  • CONTROL – MODULATING (Sizing available)
  • ISOLATION – ON/OFF



Wide Applications



•Power plant, Coal coking plant •Coal Washery •Wastewater treatment •Steel Corporation
•Orel Mine •Chemical Industry •Aluminum Company •Corrosive Liquid
•Pharmaceutical industry •Food process •General engineering •Sludge Control



Specifications



Size: 1” to 48”

Max working pressure: PN16 (consult for higher pressures)

Working Temperature: -20℃ to +80℃

Flange drilling: ANSI150#, ANSI 300#, DIN, JIS etc

Actuation: Double or single acting pneumatic, FO or FC

Sleeve Material: NR, EPDM, NBR, SBR, FPM, CR etc

In-line Tube Change: Available

Body type: Enclosed Or Closed Body

Body Material: Cast iron or fabricated steel



Pneumatic Actuated Handmade Sleeve Fabric Cord Enhanced Pinch Valve For Mining Pelletizing
