NR Sleeve Manual Knife Gate Slurry Valve For FGD System

NR Sleeve Manual Knife Gate Slurry Valve For FGD System
NR Sleeve Manual Knife Gate Slurry Valve For FGD System

Large Image :  NR Sleeve Manual Knife Gate Slurry Valve For FGD System

Product Details:
Place of Origin: Made In China
Brand Name: TEKO
Certification: CE Certificate
Model Number: PZ73X
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: By Negotiation
Packaging Details: By polywooden cases
Delivery Time: 15 days after deposite
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 50 tons per month
Detailed Product Description
Material: Carbon Steel Seat: Wear-resistnat NR
Bi-directional Seal: Yes Drill Standard: ANSI DIN
Function: Abrasion, Slurry Operation: Manual,Pneumatic,Gear
High Light:

Knife Gate Slurry Valve


NR Sleeve Slurry Valve

NR Sleeve Long Flange End Manual Knife Gate Slurry Valve For FGD System


Specifications & Standards


Size Range DN50~600mm Design Mill Standard
Pressure rating 150 psi(10 bar) Face to face MSS-SP-81
Body Style Two-piece bolted Drilling ASME B16.5 CL150



Design of Knife Gate Slurry Valve:


The TEKO Knife Gate Valve is bi-directional and best suited for the abrasive applications that are often encountered in the mining and industrial industries. It is one of very few in the market that has been specifically designed for your most demanding applications.


Its replaceable elastomer sleeves offer the latest technology in a reliable sealing solution.

The sleeves fully line the body of the valve ensuring no steel components come in contact with the slurry.


With no packing gland, we also have eliminated the associated actuation issues caused by slurry build-up and dewatering in and around the packing gland. It also allows the gate to eject material out of the bottom during actuation, so you can be sure of full gate closure and a reliable seal. The gate is fully out of the pipeline when open. This minimizes pressure drop across the valve.



Standard features

  • Dust boot and stem covers
  • High strength stainless steel gate clevis
  • Packing-less design
  • Epoxy-coated fabricated steel body
  • Replaceable wear sleeves
  • Upgraded zinc-plated hardware
  • Bi-directional operation
  • Machined gate guide
  • Composite air cylinder tube
  • Cylinder supplied with internal ring magnet so that reed type limit switches can be used
  • Frames can accept any type of actuator

FGD systems need reliable valves

Slurry valves, are critical in an (FGD) system in a coal power facility.Our knife gate slurry valves are ideal for flue gas desulphurization processes requiring high performance and reliability. Our valves are designed with quick and easy replaceable elastomer sleeves and gates. It is crucial for power plants to have reliable valves to keep the process moving so they can meet the demands and emission requirements without downtime. Learn more about our knife gate valves.
