Product Details:
Payment & Shipping Terms:
|
| Body Material: | Fabricated Steel | Structure: | Square Port |
|---|---|---|---|
| Standard Or Non Standard: | Non Standard | Media: | Water,coal Slurry,Gas |
| Size: | DN200xDN200.- DN1200xDN1200 | Driver: | Pneumatic, Hydraulic， Bevel Gear |
| High Light: | Metal Seat Knife Gate Valve,Resilient Knife Gate Valve,8" X 8" Knife Gate Valve |
||
Round Square Port Pneumatic Resilient Metal Seat Knife Gate Valve 8 X 8
Square Knife Gate Valve
TEKO Square Knife Gate Valve is a fabricated square or rectangular port low-pressure valve for fluids with :
The advantage of this kind of knife gate valve is that Internal design avoids any build-up of solids that would prevent valve from closing. Internal gate wedges and guides for tighter shut off.
Specifications
| Size Range | DN200xDN200.- DN1200xDN1200 |
| Pressure Range | Class 150 /PN6 /PN10 |
| Applicable Temperature | 0~200℃ |
| Connection Type | Square flange |
| Sealing material | Rubber, Metal seal |
| Body Material | Carbon steel, stainless steel |
|
Disc material
|
Stainless steel,carbon steel
|
| Operating Type | Hand wheel, Bevel Gear |
| Model | TRZ343H |
Advantages
1.The same construction as standard knife gate valve.
2.Body and gate disc in rectangular valve shape.
3.Same actuators and accessories as standard.
4.Rising stem tight model.
5.Square flange ends.
Appolications
