Manual Wafer Lugged Stainless Steel Knife Gate Valve Bi-Directional PTFE Seat

Large Image : Manual Wafer Lugged Stainless Steel Knife Gate Valve Bi-Directional PTFE Seat

Product Details:

Place of Origin:	Made In China
Brand Name:	TEKO
Certification:	CE Certificate
Model Number:	PZ73H

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	By Negotiation
Packaging Details:	By polywooden cases
Delivery Time:	15 days after deposite
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	50 tons per month

Contact Now

Detailed Product Description

Material:	Stainless Steel	Seat:	Resilient Seat, Metal Seat
Drill Standard:	ANSI DIN	End:	Lug, Semi Lug
Application:	Water Oil	Opeartiong:	Handwheel, Pneumatic
High Light:	Wafer Lugged Knife Gate Valve , PTFE Seat Knife Gate Valve

Manual Wafer Lugged Bi-directional PTFE Seat Stainless Steel Knife Gate Valve

TEKO Stainless Steel wafer knife gate valve with resilient seat (NBR), or metal seat (the metal to metal seat will not give a bubble tight seal on liquids) and 316 stainless steel gate. Operated by a rising stem hand wheel and suitable up to 10 BAR media pressure. Suitable for slurries, effluent, wine industry and sewerage treatment plants. Unique design allows for a long life and low maintenance once installed. Other flanges available upon request. Designed in accordance with MSS SP-81.

Options include chain drive, lever operation, extension shaft and deflector cone.

Dimensions:

Manual Wafer Lugged Stainless Steel Knife Gate Valve Bi-Directional PTFE Seat 0

N	L	D1 (PCD)	d (bore)	N-M	H
50	42	114	45	4-M16	320
65	43	127	60	4-M16	325
80	45	146	74	4-M16	360
100	45	178	93	8-M16	400
125	52	210	116	8-M16	441
150	52	235	138	8-M20	507
200	65	292	188	8-M20	625
250	70	356	233	12-M20	770
300	70	406	281	12-M22	873
350	70	470	330	12-M22	981
400	96	521	368	12-M22	1098
450	108	584	415	16-M22	1219
500	121	642	460	16-M22	1329
600	148	756	560	16-M22	1553

Features:

Designed for easy, quick conversion between manual and pneumatic actuation. Featuring a lubricant injection port for continuous, smooth operation with minimal maintenance
Smart design and horizontal bolting stabilizes gate ensuring proper alignment
Standard multi-layer square packing provides exceptional gland sealing
Optional energized quad seal packing for enhanced gland sealing
Standard integral metal seat with optional replaceable Class IV metal or Class VI resilient seats
Deflection resistant gate design ensures consistent alignment for industry leading durability
Unique body design with no dead pockets enables self-draining of valve
Lugged body suitable for all mounting orientations including dead-end service
