Flange End Soft Seated CF3M Segment Ball Control Valve

Flange End Soft Seated CF3M Segment Ball Control Valve
Flange End Soft Seated CF3M Segment Ball Control Valve

Large Image :  Flange End Soft Seated CF3M Segment Ball Control Valve

Product Details:
Place of Origin: Made in China
Brand Name: TEKO
Certification: CE/PED, API
Model Number: VQ71H,VQ41F
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: By negotiation
Packaging Details: By export wooden cases
Delivery Time: 15 working days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per year
Detailed Product Description
Driven By: Manual, Penumatic, Electric As Requested Body Material: WCB, CF8,CF8M, CF3,CF3M
Operation: Pneumatic, Spring Return Seat Material: Harden Face
Structure: V Notch End Connection: Flange,Wafer
Positioner: Optional
High Light:

flanged end ball valve

,

v port ball valve

Flange End Soft Seated Pneumatic Segment Ball Control Valve For Foo Industry



ABOUT SEGMENT BALL VALVE

TEKO Segment ball valve designed for throttling or on/off application in various applications including juice, starch, syrup, water and oil.

Segment ball valve is one type of ball valves, its closure is a half ball with V type port which has sharp edges. during operation the valve, friction action will be occurred between its closures that producing a strong shearing force to the medium, and a fan-shaped area will be formed between V type port of the ball and the port of seat ring, so the section are of flow port can be changed, and the medium can be precisely regulated. it is a kind of regulating valve with angle rotation, having same sealing performance as common ball valves, so it simultaneously has both functions of regulating and on-off . Incorporating with pneumatic or electric actuators, it can be widely used in the automatic control systems in different industries.

Segment ball valve features a characterized ball segment for high rangeability with splined stem connection for precise control, maintenance friendly segment-stem assembly, low friction shaft and thrust bearings for longer life, integral actuator mounting pads, and interchangeable seats.



MAIN FEATURES

1. Lost-wax precision casting.
2. Fire safe design approved.
3. Built-in ISO 5211 direct mounting pad for easy automation.
4. Anti-static devices for ball-stem-body.
5. Blow-out proof stem.
6. pressure balance hold in ball slot.





DESIGN STANDARD



END FLANGE: EN1092-1:2001, ASME B16.5, GB/T 9113.1-2010, JB/T 79.1-1994, HG 20592-2009

PRESSURE TEMPERATURE RATING: ISO7005-1, ASME 16.34-2003, GB/T 12224-2007
FACE TO FACE: Wafter type –Mill standard, Flange type – ISA S75.04-1995, IEC/DIN 534-3-2
WORKING TEMPERATURE:

Normal, Middle and High
