Bi - Directional Automated SS API609 Butterfly Valve Wafer Lug Low Pressure

China Bi - Directional Automated SS API609 Butterfly Valve Wafer Lug Low Pressure supplier

Large Image :  Bi - Directional Automated SS API609 Butterfly Valve Wafer Lug Low Pressure

Product Details:

Place of Origin: Made in China
Brand Name: TEKO
Certification: CE, API
Model Number: D71X

Payment & Shipping Terms:

Minimum Order Quantity: 1 pieces
Price: By negotiation
Packaging Details: Pollywooden cases
Delivery Time: 15 days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per year
Contact Now
Detailed Product Description
Manufacture: API 609 Stem Materail: SS410, F304
Installation: Any Direction Operation: Manual
End: Wafer, Lug Port Size: Standard,DN50-DN300
Rating: 285PSI

Wafer Lug Low Pressure Bi-directional Automated SS Butterfly Valve



Quick Info

  • Soft-seated butterfly valve
  • Centric design, for installation between flanges
  • DIN EN 1092-1, PN 10/16, ANSI 150 lbs
  • Two-piece body, self-centering, one-piece disc/stem
  • DN 50 – DN 300



TEKO Automation System



TEKO industry valves / valves - We also deliver butterfly valves, control valves, valves, rupture discs, valves as slide valves, knife gate valves and double eccentric valves, triple eccentric valves, ball valves, flanged ball valves, 3-piece ball valves, diaphragm pumps, PTFE-lined butterfly valves, Valves, throttle valves, return valves, ball segment valves, tire valves



Features



1. AUTOMATION SYSTEM

  • Standard flange acc. to DIN 3337
  • Direct actuator mounting without interruption of the stem
  • Variable and exchangeable for any actuator size
  • Actuator protection against leakage

2. TWO-PIECE BODY
Standard overall length; very service friendly, simple exchange of internal parts possible because of the two-piece body design



3. BEARING

including O-ring



4. PRIMARY SEAL
Has a labyrinth layout and is integrated in the seat. This construction guarantees the cavity-free and pressure-resistant sealing to the outside



5. SEAT
Multifunctional seal element, easy to replace, maintenance free, long service life, tight shut-off in the seat, to the flanges and the shaft. Based on the construction (dovetail) the seat is safely locked between body and flanges, embedded in the body without edge protruding over the flange area



6. DISC / STEM

One-piece design, absolutely free of play, large free cross-section, minimal pressure loss



APPLIATIONS

Agricultural irrigation Water distribution Waste water treatment
Pulp & pater Chemical Oil & gas
