Product Details:
Payment & Shipping Terms:
|
Operation: | Pneumatic | Applicationg: | Slurry, Paper Pulp |
---|---|---|---|
End Connection: | Wafer, Lug | Seat Material: | EPDM Or Metal Seated |
Surface Treatment: | Powder Coating | Design: | MSS SP-81 |
High Light: | 4 inch knife valve,cast steel valves |
MSS-SP81 Standard Soft Seated Pneumatic Actuated Knife Valves For Paper Pulp
Description
Wafer to suit PN10, ductile iron Body, Stainless Steel Knife, EPDM Seat, Double Acting Actuator, Rated PN10 2” to 6”, PN8 8”, PN7 10”, PN6 12” & 14”, PN5 16”, Temperature -35°C to 120°C. Note: NBR & Metal Seat options & larger sizes available.
Additional Information
Fitting | PN10, ANSI 150Lb |
Material | Ductile Iron |
Size (in or mm) | 3″, 4″, 5″, 6″, 8″, 10″, 12″ |
DN | L | O | D | S | C | f | M-1 | B | H | Weight (KGS) |
50 | 40 | 165 | 125 | 95 | 16 | 2 | 4-M16 | 136 | 430 | 7 |
65 | 40 | 185 | 145 | 110 | 16 | 2 | 4-M16 | 151 | 460 | 9 |
80 | 50 | 200 | 160 | 127 | 17 | 2 | 8-M16 | 170 | 510 | 12 |
100 | 50 | 220 | 180 | 148 | 17 | 2 | 8-M16 | 190 | 570 | 14 |
125 | 50 | 250 | 210 | 174 | 17 | 2 | 8-M16 | 212 | 660 | 22 |
150 | 60 | 285 | 240 | 199 | 21 | 2 | 8-M20 | 230 | 720 | 25 |
200 | 60 | 340 | 295 | 250 | 21 | 2 | 8-M20 | 286 | 890 | 38 |
250 | 70 | 395 | 350 | 308 | 24 | 2 | 12-M20 | 338 | 1120 | 65 |
300 | 70 | 445 | 400 | 360 | 24 | 2 | 12-M20 | 388 | 1230 | 77 |
350 | 96 | 505 | 460 | 416 | 33 | 2 | 16-M20 | 460 | 1370 | 195 |
400 | 100 | 565 | 515 | 466 | 35 | 2 | 16-M24 | 520 | 1570 | 240 |
450 | 106 | 615 | 565 | 525 | 36 | 2 | 20-M24 | 585 | 1720 | 306 |
500 | 110 | 670 | 620 | 584 | 37 | 2 | 20-M24 | 635 | 1850 | 365 |
600 | 110 | 780 | 725 | 664 | 37 | 2 | 20-M27 | 720 | 2150 | 420 |
