Pneumatic V Port Flanged Ball Valve , V Control Regulating Wafer Ball Valve

Large Image : Pneumatic V Port Flanged Ball Valve , V Control Regulating Wafer Ball Valve

Product Details:

Place of Origin:	Made in China
Brand Name:	TEKO
Certification:	CE/PED, API
Model Number:	VQ71H,VQ41F

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	By negotiation
Packaging Details:	By export wooden cases
Delivery Time:	15 working days after deposit
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	300 tons per year

Contact Now

Detailed Product Description

Driven By:	Manual, Penumatic, Electric As Requested	Body Material:	WCB, CF8,CF8M, CF3,CF3M
Port Size:	Reduced Port	Seat Material:	Stellite Coating, Nutride Coating
Structure:	V Port	End Connection:	Flange
High Light:	flanged end ball valve , v port ball valve

Pneumatic V Port Flanged Ball Valve V Control Regulating Ball Valve Wafer

Application:

Applied to control and regulate the fluid containing fibers or high-viscosity fluid containing solid particles. It can also be used as the isolating valve for its reliable sealing. It is widely employed in chemical industry, paper-making, petroleum, electric power, etc.

Structure

Wafer: DN25-DN250 (1”-10”)
Flange: DN300-DN500

Pressure:
DIN: PN1.0, PN1.6, PN2.5, PN4.0
ANSI: 150Lb, 300Lb

Features:

* Side entry internal body, durable structure, free from distortion and leakage.
* Self-lubricated bearing was connected between the upper/bottom stem with body, which makes a light torque.
* Different materials are available upon working conditions
* Good regulation. V port ball will keep flow rate in a geometry scale. And its rangeability is up to 300:1.
* Compact Structure, easy for installation and maintenance.

Image:

Pneumatic V Port Flanged Ball Valve , V Control Regulating Wafer Ball Valve 0
