Carbon Steel Rising Stem PN10 PTFE Lined Valves

Carbon Steel Rising Stem PN10 PTFE Lined Valves
Carbon Steel Rising Stem PN10 PTFE Lined Valves

Large Image :  Carbon Steel Rising Stem PN10 PTFE Lined Valves

Product Details:
Place of Origin: Made in China
Brand Name: TEKO
Certification: CE/PED, API
Model Number: QZ41F4
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: By negotiation
Packaging Details: By export wooden cases
Delivery Time: 15 working days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200 tons per year
Detailed Product Description
Operation: Handwheel, Bevel Gear TEST: API 598
Presssure: PN10/16, 150Lb Liner Material: PO,PP, PTFE, PFA
Structure: Gate Test Standard: API 598
High Light:

PN10 PTFE Lined Valves


API 598 PTFE Lined Valves


DIN Ptfe Lined Gate Valve

Carbon Steel Chemical Solution Rising Stem PTFE lined Valve China


Products Description

  • Gate valve can be divided into rising stem gate valve, which refers to the disc doing lift movement in straight line along with the valve stem, and non-rising stem gate valve which refers to the stem nut located in the disc, when the stem rotates, the disc doing lift movement in straight line.
  • TEKO lined gate valve adopts new design structure, solving the inconvenient or jammed operation phenomenon caused by particles, fibers and medium deposition in the screw groove of common non-rising gate valve.
  • Valve installation position is not subject to any restrictions.
  • It can sustain any corrosive medium in addition to the molten alkali metals and fluorine elements. It is ideal products used in chlor-alkali, industrial in organic chemicals, metal and mining, nitrogen and phosphatic fertilizers, petroleum refining, pharmaceutical etc.
  • Lining material: PFA, FEP, GXPO etc.
  • Operation methods: manual, worm gear, electric, pneumatic and hydraulic actuator.
  • The lined gate valves are available as per the needs of applications in additional sizes and other than standard materials.




Design/Manufacturer Standard ASME B16.34, HG/T 3704
Face-to-face Dimension ASME B16.10 , GB/T 12221
Flange Standard ASME B 16.5 ,GB/T 9119 ,DIN ,JIS
Inspection and Testing API 598, GB/T 13927



Carbon Steel Rising Stem PN10 PTFE Lined Valves 0

  • Model NO.: Z41PFA-16C
  • Material: Carbon Steel
  • Pressure: Low Pressure
  • Seal Surface: Wedge Gate Valve
  • Usage: Drain
  • Application: Industrial Usage
  • Size: Dn15~300
  • Specification: TS, CE, SGS
  • Type: Straight-through
  • Connection Form: Flange
  • Actuator: Manual
  • Thread Position of Valve Rod: Outside Gate Valve
  • Standard: DIN
  • Materials: Wcb+PFA
  • Medium: Corrosion Medium
  • Transport Package: Plywood Case
