| Material: | Aluminum Alloy | Rotary Angle: | 90°±5° |
|---|---|---|---|
| Protection Class: | IP68 | Conneciton Type: | ISO 5211, Star Square |
| Torque Range: | 70-6000 Nm | Voltage: | 220VAC, 24V DC Upon Customer Request |
| High Light: | Manual Override Smart Electric Actuator,2A 250VAC Smart Electric Actuator,Aluminum Alloy Smart Electric Actuator |
||
Fast Action Smart Manual Override Electric Quarter Turn Actuator With Switch Knob
TG-R series fast part turn electric actuator is newly designed and developed for quarter turn operating applications such as Ball, Butterfly, Plug valves, Dampers and similar usages.TEKO's electric actuators serve all over the world, including Europe, the Americas, ICAO, Australia, Africa, Asia, the Middle East and Southeast Asian countries. It is widely used in water treatment, heating, petroleum, chemical industry, electronics, light industry, food, medicine, textile, paper making, hydropower, ships, smelting, new energy and other fields.
Feature
Torque range:70~6000N.m
Switching time:20~120 S
Protection:IP67, (IP68 optional)
Voltage:AC110~265V , AC / DC 24V Multi voltage input
Mounting Flange(ISO 5211):F04/F05/F07/F10/F12/F14/F16
Output signal(On-off type): Fully open & fully close passive contact(2A 250VAC).
Type of On-off Signal: Contact signal. Mechanical Switch
Type of Modulating Signal: 0-10V, 2-10V, 4-20mA, etc.
Parameters
| Model | Max output torque | Operating | Drive shaft(mm) | Power | Rated current(A) | Weight | |
| Time 90° | |||||||
| N·M | ( 90°) | Square | Deep | (W) | 220VAC/1ph | (kg) | |
| TG-R-08 | 70 | 20 | 12×12 | 12 | 15 | 0.18 | 2.8 |
| TG-R-18 | 150 | 30 | 15×15 | 19 | 40 | 0.25 | 4 |
| TG-R-28 | 250 | 30 | 23×23 | 20 | 60 | 0.12 | 7.5 |
| TG-R-100 | 1000 | 60 | 30×30 | 26 | 130 | 0.9 | 11.6 |
| TG-R-200 | 2000 | 90 | 30×30 | 26 | 130 | 0.9 | 11.6 |
| TG-R-400 | 4000 | 90 | 52×52 | 30 | 300 | 1.97 | 30.5 |
| TG-R-600 | 6000 | 120 | 52×52 | 30 | 500 | 1.1 | 30.5 |
