Stainless Steel 304 Globe Valve Metal - To - Metal Seat For Oxygen Service

China Stainless Steel 304 Globe Valve Metal - To - Metal Seat For Oxygen Service supplier

Large Image :  Stainless Steel 304 Globe Valve Metal - To - Metal Seat For Oxygen Service

Product Details:

Place of Origin: Made in China
Brand Name: TEKO
Certification: CE/PED, API
Model Number: J41W

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: By negotiation
Packaging Details: By export wooden cases
Delivery Time: 15 working days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 350 tons per year
Contact Now
Detailed Product Description
Flange End: ASME B16.5 Design: BS 1873
Seat Materail: Metal-to-metal Seat Body Material: Carbon Steel, Stainless Steel
Pressrue Rating: 150LB-1500Lb Face To Face: ASME B 16.34

Stainless Steel 304 Stop Regulating Valve BS1873 Globe Valve In CF8 / CF8M / CF3 / CF3M



Optional Features:



Bellow sealed globe valves

Pressure sealed bonnet globe valves

Globe valves for Oxygen service

Cryogenic globe valves

"Y" pattern globe valves

"T" pattern globe valves

Combined globe & check valves

Custom made globe valves



Applicable Standards:



Steel globe valves, BS 1873 / API 600 / API6D

Steel valves: ASME B16.34

Face to face: ASME B16.10, DIN 3202, EN 558

Flanges end: ASME B16.5

Butt welding ends: ASME B16.25

Inspection and test: API 598, ISO 5208



Speciality:



A. Anti-friction ball thrust bearing:

Reduce friction between mating parts to ensure smooth operation
B. Grub screw:

Secures yoke nut in the bonnet
C. Grease nipple:

Supplies lubricant to the mating parts

D. 24HOURS SERVICE.

E. Fugitive Emission Testing



Material List



No. Parts Name Material
1 Body ASTM A216 Gr.WCB
2 Seat Ring ASTM A105+13Cr
3 Disc ASTM A105+13Cr
4 Stem ASTM A182 F6a
5 Gasket 304SS Jackted Graphite
6 Bonnet ASTM A216 Gr.WCB
7 Stud ASTM A193 Gr.B7
8 Nut ASTM A194 Gr.2H
9 Back Seat ASTM A 276 410
10 Packing Graphite
11 Gland Bolt ASTM A 193 Gr.B7
12 Gland Nut ASTM A194 Gr.2H
13 Bushing ASTM A276 410
14 Pin C.S.
15 Gland ASTm A 216 Gr.WCB
16 Stem Nut Aluminum Bronze
17 Screw C.S.
18 Handwheel Malleable Iron
19 Washer C.S.
20 Nut C.S.
21 Disc Cover ASTM A276 410
22 Washer S.S

Note: Materials of Globe Valve Body: ASTM A216 WCB, A352LCB, A217WC1, WC6, WC9, C5, A351 CF8 CF8M CF3 CF3M etc.





FAQ



1. What’s your products range?
-Forging and casting
-Duplex, Super Duplex, Inconel, Monel, Hastelloy, Aluminium Bronze.
-Ball valve,Butterfly valve,Gate valve,Globe valve,Check valve, Strainer & Other valves.
2. Do you have stock products to sell?
-Yes, we have normal type with normal material in stock
3. What information do you need if I want to inquiry?
-The valve type, size, pressure and material.
-The liquid,connection and operation also need if you can offer.
4. Can I get some samples?
A:Yes.Sample fee will be for buyers account
5. Could I use my own LOGO or design on goods?
-Yes. Customized logo and design on mass production are available.
6. How many days the products will be ready?
-Generally,3 to 4 weeks,depends on the quantity.
7. May I visit your factory?
-Sure,wlcome any time.We can also pick you up at airport and station.P506
