Manual Operation BS 1873 Globe Valve , Flanged Globe Valve With Standard Wall Thickness

China Manual Operation BS 1873 Globe Valve , Flanged Globe Valve With Standard Wall Thickness supplier

Large Image :  Manual Operation BS 1873 Globe Valve , Flanged Globe Valve With Standard Wall Thickness

Product Details:

Place of Origin: Made In China
Brand Name: TEKO
Certification: CE Certificate
Model Number: J41H

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: By negotiable
Packaging Details: By polywooden case
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 tons per month
Contact Now
Detailed Product Description
Material: WCB End: Flange
Operation: Manual Standard: BS1873
Certificate: CE

BS API 16.34 Manual Operation Globe Valve With Standard Wall Thickness





Globe Valves



The globe valve is used for throttling flow control. Shut off is accomplished by moving the disc against the flow stream rather than across it as in the case with a gate valve. The flow pattern through a globe valve involves changes in direction, resulting in greater resistance to flow, causing high pressure drop. The globe valve is an excellent valve to use for on-off service, but is highly suited for frequent cycling and control of fluids anywhere in amount or volume between the open and closed positions.

The globe valve must be installed in the proper relation to the media flow as indicated by the flow direction arrow marked on the valve body. This valve is considered uni-directional and must be installed with the pressure side or inlet under the seat.

TEKO Valves globe product line are manufactured as full port, with threaded, socket-weld, flanged and butt weld ends. Pressure classes include 150 through 1500. From our Houston, Texas manufacturing facility, we offer valves in the following materials: CF8M, CF3M, CF8, CF3, CK20, CG8M, CF8C, CN7M, CW12MW, CY40, CW6MC, N12MV, N7M, M35-1, CZ100, CD3MN and many others.



Design Highlights


• Bolted Bonnet – Confined Bonnet Gasket
• Outside Screw & Yoke (OS & Y)
• Full Port
• Metal / Renewable Disc Available
• Special Trims available
• Teflon (Braided or Chevron), Flexible Graphite or other packings and gasket combinations available
• Flanged, Butt Weld, Threaded and Socket Weld available
• API 623 available
• Valve design per ASME B16.34



Standards:

All valves are manufactured in accordance with the latest industry standards listed below as applicable:

ASME B16.34 Valves, Flanged, Threaded and Welding End
API 623 Steel Globe Valves - Flanged and Butt Welding Ends, Bolted Bonnet
ASME B16.10 Face-to-Face and End-to-End Dimensions of Valves
ASME B16.11 Forged Fittings, Socket Welding and Threaded
ASME B16.25 Butt Welding Ends
ASME B16.5 Pipe Flanges and Flanged Fittings
API 598 Valve Inspection and Testing
MSS SP-25 Standard Marking System for Valves, Fittings, Flanges and Unions
MSS SP-42 Corrosion Resistant Gate, Globe, Angle and Check Valves
MSS SP-61 Pressure Testing of Valves



Manual Operation BS 1873 Globe Valve , Flanged Globe Valve With Standard Wall Thickness  Manual Operation BS 1873 Globe Valve , Flanged Globe Valve With Standard Wall Thickness
